Figure 6 - Measurement of canoe body draft
Bc is the chine beam, to be taken as the maximum waterline beam, according to Figure 2; τ is the running trim angle, but not to be taken less than 3°; β is the deadrise angle, to be determined from Figure 3, but not to be taken less than 30°.
Bc is the chine beam, to be taken as the maximum waterline beam, according to Figure 2;
τ is the running trim angle, but not to be taken less than 3°;
β is the deadrise angle, to be determined from Figure 3, but not to be taken less than 30°.
