2. PLiB Dictionary, STEP Schema
PLiB dictionary is expressed based on the IS0-13584, as Part21 files PumpDictionary.dic and HeatExchangerDictionary.dic.
- This dictionary is a proto type for this project, and the BSU code is not same as one of ISO 10303-226.
AP226 STEP schema is basically in ARM level in this project, but experimental implementation using AIM is also tried.
Class BSU
Pump:MPC_00200
Heat Exchanger:MPC_00300
