Notes

Colour of the circle and a letter at the right side of the symbol should indicate as follows：

A - (blue) for accommodation and service spaces

M - (green) for machinery spaces

C - (yellow) for cargo spaces

　

Notes

Colour of the upper part and letter at the right side of the symbol should indicate as follows：

A - (blue) for accommodation and service spaces

M - (green) for machinery spaces

C - (yellow) for cargo spaces

　

Notes

Colour of the symbol and letter on top should indicate as follows：

Grey - CO₂ for carbon dioxide

Yellow - F for foam

Brown - H for halon or halon equivalent

White - P for powder

Green - W for water

Orange - S for sprinkler

　
