Notes

Indicate type of media and capacity (kg for CO₂ and powder and halon or halon equivalent, I for water and foam) at the right of the symbol. Extinguishing media should be colour coded in the lower part of the symbol and indicated by a letter at the right side of the symbol as follows：

Grey - CO₂ for carbon dioxide

Yellow - F for foam

Brown - H for halon or halon equivalent

White - P for powder

Green - W for water

　

Note

Indicate at the right side of the symbol the number of the fire locker.

　

Note

Indicate at the right side of the symbol the number of the safety locker.

　
